每一款標準的風冷卻器產品，都有對應的性能曲線圖，

用戶根據曲線圖選型，依據的是兩個必要的參數：

第一，實際的流量，

第二，當量冷卻功率，也叫等比比散熱功率。

所以，這兩個參數都不知道，或者只知道其中一個，都不能準確選擇風冷卻器。

這對于使用者來說，是有風險的。我們常常告訴他們，核心的參數不夠，無法推薦合適的產品。因?yàn)檫x大的或選小了都會造成浪費。

這是一件令人沮喪的事情。

但不是一件困難的事情。

所以，使用者或廠家十分必要搞清楚風冷卻器這兩個參數。

有一個簡單的計算公式，提供給大家，

根據風冷卻器的進出口油溫，估算系統的散熱量，

Pv≈0.028×L×(T進-T出)

T進：液壓油進口溫度（℃）

T出：液壓油出口溫度（℃）

Pv：散熱量

L:油的流量（l/min）

如果不能提供上面的兩個參數，就只能依據液壓系統總功率的1/3作為風冷卻器選型的參數。

Two necessary parameters for selection and calculation of air cooler



Each standard air cooler product has a corresponding performance curve,



According to the curve chart, the user selects the model based on two necessary parameters:



First, the actual flow,



Second, the equivalent cooling power, also known as the proportional cooling power.



Therefore, neither of these two parameters, or only one of them, can accurately select the air cooler.



This is risky for users. We often tell them that the core parameters are not enough to recommend the right products. Because choosing the big one or the small one will cause waste.



This is a depressing thing.



But it's not a difficult thing.



Therefore, it is very necessary for users or manufacturers to understand the two parameters of air cooler.



There is a simple calculation formula for you,



According to the oil temperature at the inlet and outlet of the air cooler, the heat dissipation of the system is estimated,



Pv ≈ 0.028 × L × (T in - T out)



T inlet: hydraulic oil inlet temperature (℃)



T outlet: outlet temperature of hydraulic oil (℃)



Pv: heat dissipation (kw)



L: oil flow (L / min)



If the above two parameters cannot be provided, only 1 / 3 of the total power of the hydraulic system can be used as the parameters of air cooler selection.
